6-S Shaking Table

6-S type glass fiber reinforced plastic shaker

Product introduction

6-S shaking table is the core sorting equipment in the field of gravity beneficiation, known for its excellent sorting precision and stable operation performance. It adopts glass fiber reinforced plastic bed, and can efficiently separate mineral particles with different specific gravity through the effect of compound force field. It is widely used in the roughing, selecting and sweeping operations of rare metals, precious metals and non-metallic minerals, and is the ideal sorting equipment for mine processing plant.

Core Advantages

1. Excellent sorting efficiency

• High recovery and enrichment ratio: it can accurately separate minerals with small differences in specific gravity, and at the same time obtain high-grade concentrate and high recovery.

• Wide range of particle size adaptability: It can effectively handle a wide range of particle sizes from coarse sand (2mm) to very fine sludge (0.022mm), making it a multi-purpose machine.

2. Flexible operation adjustment

• Stepless adjustable parameters: the stroke, stroke and lateral slope of the bed surface can be easily adjusted, and can be quickly optimized to adapt to the process requirements of different minerals.

• Stable and reliable operation: the bed surface moves smoothly, the sorting belt is clear, which can ensure the continuous and stable production for a long time, and the fluctuation of sorting index is small.

3. Durable design

• High-quality glass fiber reinforced plastic (FRP) bed surface: up to 7 kinds of striped bed surface are available, with high strength, abrasion and corrosion resistance, and the service life is much longer than that of the traditional wooden bed surface.

• Innovative structural design: built-in springs, compact structure, strong transmission mechanism, significantly improving the overall stability and service life of the equipment.

4. Economical and convenient

• Simple installation and maintenance: reasonable structural design, simple foundation, quick installation and routine maintenance workload is small, low comprehensive maintenance costs.

• Energy saving and low consumption: low power consumption, no need for complex auxiliary systems, economic operating costs.

Working Principle

After the slurry is fed into the slightly inclined bed, the mineral particles are separated under the action of composite force field:

• Asymmetric reciprocating motion of the bed: positive inertial force and reverse friction are generated, making the particles move longitudinally on the bed and stratify according to specific gravity.

• Transverse current flushing: The current flushes the stratified upper layer of light mineral particles transversely to the tailings side.

• Gravity and friction: Heavy mineral particles, due to their high specific gravity, are affected by the friction on the bed surface and move along the bed streak towards the concentrate side.

Eventually, minerals with different specific gravity show clear fan-shaped zones on the bed surface, and are discharged from the concentrate end, the middle zone and the tailings side respectively, realizing precise separation.

Technical Parameters (Example)

Note: The above are general parameters, specific models may vary.

Applicable minerals and fields

• Precious metals: alluvial gold, silver ore, etc.

• Rare metals: tungsten ore, tin ore, tantalum-niobium ore, bismuth ore, etc.

• Non-ferrous metals: lead-zinc ore, copper ore, etc.

• Ferrous metals: iron ore, manganese ore, chromite ore, ilmenite ore, etc.

• Non-metal: coal, quartz, feldspar, etc.

• Others: waste recycling, soil heavy metal separation and other environmental protection fields.

Why choose our 6-S shaker?

• Proven technology: Classic 6-S structure design, mature and reliable sorting process.

• Key Material Upgrade: High-performance fiberglass bed is the core to ensure efficient sorting and long service life.

• Comprehensive adaptability: From roughing to sweeping, one machine can cover a wide range of classification needs.

• Excellent economy: low investment, low running cost, low maintenance cost, high return on investment.
